| PHYSICAL |
| Dimensions (LxWxH) |
94x19x69 mm / 3.70×0.75×2.71 in |
| Weight |
75 g / 2.7 oz |
| Ambient temperature |
-20 °C to 40 °C / -4 °F to 104 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
| Screw terminals max torque |
0.4 Nm / 3.5 lbin |
| Conductor cross section |
0.5 to 2.5 mm2 / 20 to 14 AWG (green connectors) – 0.5 to 1.5 mm2 / 20 to 16 AWG (blue connector) (solid, strand-ed, and bootlace ferrules) |
| Conductor stripped length |
6 to 7 mm / 0.24 to 0.28 in (green connectors) – 5 to 6 mm / 0.20 to 0.24 in (blue connector) |
| Power supply |
110-240 V~ 50/60 Hz |
| Power consumption |
< 2 W |
| External protection |
max. 10 A, tripping characteristic B or C,6 kA interrupting rating, energy limiting class 3 |
| Supported load types |
| HV LED lamps (Dimmable) |
200 W |
| Dimmable electronic transformers |
200 W |
| Incandescent Light bulbs |
200 W |
| HV halogen lamp |
200 W |
| Iron-core transformer |
200 VA |
| Dimming type |
Trailing edge |
| RF band |
2400 – 2495 MHz |
| Max. RF power |
< 20 dBm |
| Wi-Fi protocol |
802.11 b/g/n |
| Wi-Fi operational range (depending on local conditions) |
up to 50 m / 160 ft outdoors up to 30 m / 100 ft indoors |
| Bluetooth protocol |
4.2 |
| Bluetooth operational range (depending on local conditions) |
up to 30 m / 100 ft outdoors up to 10 m / 33 ft indoors |
| CPU |
ESP32-D0WDQ6 |
| Flash |
8 MB |
| Schedules |
20 |
| Webhooks (URL actions) |
20 with 5 URLs per hook |
| Scripting |
Yes |
| MQTT |
Yes
|
