3S Battery Protection Board 12V 100A – 18650 Lithium 3.2V LiFePO4

High quality lithium battery charging module 3S, 12 Volt, 100 Ampere. Single cell battery overcharge protect recover voltage : 3.61-3.69V. LFP cell has 3.2V nominal working voltage and shall be cut-off power at 3.6-3.8V per cell during charging. Charging voltage: 14.4V (3.6V * 4 = 14.4V), please this is for 3.2V rated voltage battery NOT 3.6/3.7V.

Lithium Iron Phosphate (LiFePO4, LFE) is kind of Li-Ion rechargeable battery for high power applications, such as EV car , Power Tool and RC hobby. LiFePO4 cells feature with high discharging current, non explosive, long cycle life.

Feature:

Protection project	Min	Typ	Max	Unit
Overcharge voltage	3,61	3,65	3,69	V
Overcharge recovery voltage	3,50	3,55	3,60	V
Overcharge protection delay	500	1000	1500	mS
Over discharge voltage	2,27	2,35	2,43	V
Overdischarge recovery voltage	2,45	2,55	2,65	V
Over voltage protection delay	500	1000	1500	mS
Over discharge protection current		100		A
Split discharge current (continuous)		50	80	A
Same port discharge current (continuous)		40	60	A
Over discharge protection delay	100	200	300	mS
Overcharge protection current		100
Charging current (continuous)		40	60	A
Overcharge current protection delay	10	20	30	mS
Quiescent current		17	25	uA
Temperature protection		With temperature control interface
Disconnection protection		Yes
Short circuit protection		None
Over current protection recovery mode		Disconnect the load release
Balance function		Yes
Equalizing voltage		3,405		V
Equalizing current		60		mA
Fuselage size		62424		mm
Body color		White (PCB)
