| Physical |
| Size (HxWxD): |
29x34x16 ±0.5 mm / 1.11×1.34×0.63 ±0.02 in |
| Weight: |
18 ±1 g / 0.63 ±0.04 oz |
| Mounting: |
Wall box |
| Screw terminals max torque: |
0.4 Nm / 3.5 lbin |
| Conductor cross section: |
0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules) |
| Conductor stripped length: |
6 to 7 mm / 0.24 to 0.28 in |
| Shell material: |
Plastic |
| Color: |
Red |
| Environmental |
| Ambient temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
| Humidity |
30 % to 70 % RH |
| Max. altitude |
2000 m / 6562 ft |
| Electrical |
| Power supply: |
110 – 240 VAC / 24 – 30 VDC |
| Relay: |
NO contact, 1-pole, µ contact |
| External protection: |
10 A, tripping characteristic B or C, |
| |
6 kA interrupting rating, |
| |
Energy limiting class 3 |
| Power consumption: |
|
| Output circuits ratings |
| Max switching voltage AC: |
240 V |
| Max switching voltage DC: |
N/A |
| Max switching current AC: |
8A |
| Max switching current DC: |
N/A |
| Max switching power AC: |
2000 W |
| Power measurement: |
Yes |
| Voltage protection / Cutoff: |
Yes |
| Current protection / Cutoff: |
Yes |
| Max power protection / Cutoff: |
Yes |
| Radio |
| RF band: |
2400 – 2495 MHz |
| Max. RF power: |
|
| Wi-Fi protocol: |
802.11 b/g/n |
| Wi-Fi Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors |
| |
(Depends on local conditions) |
| Bluetooth Protocol: |
4,2 |
| Bluetooth Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors |
| |
(Depends on local conditions) |
| MCU |
| CPU: |
ESP-Shelly-C38F |
| Flash: |
8 MB |
| Firmware capabilities |
| Schedules: |
20 |
| Webhooks (URL actions): |
20 with 5 URLs per hook |
| MQTT: |
Yes |
| UPD: |
Yes |
| Scripting: |
Yes
|
