Shelly 1 Mini Gen3

Product Weight: 0.0200KG

Shelly 1 Mini Gen3

Specifications

Physical
Size (HxWxD):	29x35x16 ±0.5 mm / 1.11×1.35×0.63 ±0.02 in
Weight:	19 ±1 g / 0.65 ±0.04 oz
Mounting:	Wall box
Screw terminals max torque:	0.4 Nm / 3.5 lbin
Conductor cross section:	0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
Conductor stripped length:	6 to 7 mm / 0.24 to 0.28 in
Shell material:	Plastic
Color:	Blue
Environmental
Ambient temperature:	-20 °C to 40 °C / -5 °F to 105 °F
Humidity	30 % to 70 % RH
Max. altitude	2000 m / 6562 ft
Electrical
Power supply:	110 – 240 VAC
Relay:	Dry, NO contact, 1-pole, µ contact
External protection:	10 A, tripping characteristic B or C,
	6 kA interrupting rating,
	Energy limiting class 3
Power consumption:	< 1.2 W
Output circuits ratings
Max switching voltage AC:	240 V
Max switching voltage DC:	30 V
Max switching current AC:	8A
Max switching current DC:	5A
Max switching power AC:	2000 W
Max switching power DC:	150 W
Power measurement:	No
Voltage protection / Cutoff:	No
Current protection / Cutoff:	No
Max power protection / Cutoff:	No
Radio
RF band:	2400 – 2495 MHz
Max. RF power:
Wi-Fi protocol:	802.11 b/g/n
Wi-Fi Range:	Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
	(Depends on local conditions)
Bluetooth Protocol:	4,2
Bluetooth Range:	Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
	(Depends on local conditions)
MCU
CPU:	ESP-Shelly-C38F
Flash:	8 MB
Firmware capabilities
Schedules:	20
Webhooks (URL actions):	20 with 5 URLs per hook
MQTT:	Yes
UDP:	Yes
Scripting:	Yes
