RS485 CAN HAT for Raspberry Pi

Overview

The RS485 CAN HAT will enables your Pi to communicate with other devices stably in long-distance via RS485/CAN functions.
Features

• Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
• CAN function, onboard CAN controller MCP2515 via SPI interface, onboard transceiver SN65HVD230
• RS485 function, controlled via UART, half-duplex communication, supports automatic TX/RX control without programming, onboard transceiver SP3485
• Onboard TVS (Transient Voltage Suppressor), effectively suppress surge voltage and transient spike voltage in the circuit for RS485 transceiving, lightningproof & anti-electrostatic
• Reserved control pins, allows to work with other control boards
• Comes with development resources and manual (examples in wiringPi/python)

Specifications

• Operating voltage: 3.3V
• CAN controller: MCP2515
• CAN transceiver: SN65HVD230
• 485 transceiver: SP3485
• Dimension: 65mm x 30mm
• Mounting hole size: 3.0mm

Pinouts

Wiki : www.waveshare.com/wiki/RS485_CAN_HAT
