Product Weight: 0.8000KG
Raspberry Pi offers cost-effective, high-performance computing for businesses and the home. Designed and manufactured in the UK.
Με το παρακάτω script πολύ γρήγορα και εύκολα γίνεται εγκατάσταση ο οδηγός της οθόνης. Οπότε μετά από μια καθαρή εγκατάσταση raspberry Pi OS 64bit εκτελούμε το παρακάτω script :
curl -s https://apt.edatec.cn/bsp/ed-install.sh | sudo bash -s “hmi3010_070c”
| ED-HMI3010 |
|||||||||
| Model No. | LCD Size | Resolution | Aspect ratio | # of Colors | Luminance (cd/m2) |
Viewing Angle (H/V) |
Multi-touch (# of points) |
Dimensions (mm) |
Weight (g) |
| HMI3010-070C | 7″ | 1024×600 | 16:9 | 16.7M | 400 | 160°/160° | 10 | 188mm x 123mm x 39mm | 800g |
Document Download
| Explore in-depth reviews and coverage of ED-HMI3010 by leading international media outlets! Click the links to learn more： |
| Tom’s HARDWARE |
| CNX SOFTWARE |
| Hackster.io |
| Touch Screen | |
| Type | Multi-point Capacitive Touch Screen |
| Transmittance | ≥85％ |
|
Connection Method
|
COF |
|
Controller Interface
|
I2C |
| Driver Support | Linux |
| Multi-touch | 10 points |
|
Surface Hardness
|
6H |
|
Mechanical Characteristics
|
||
| ED-HMI3010-070C | ED-HMI3010-101C | |
| Dimensions | 188mm x 123mm x 39mm (WxDxH) |
258mm x 172mm x 38mm (WxDxH)
|
| Weight | About 800g |
About 900g
|
| Installation | Embedded front installation |
Embedded front installation
|
| Environmental & Regulatory | |
|
Operating Temperature
|
-20℃~60℃ |
|
Storage Temperature
|
-20℃~60℃ |
|
Ambient Humidity
|
5% ~ 95% (non-condensing) |
| Certifications |
FCC
FCC 47 CFR Part 15 Subpart B
CE EN IEC 62368-1/EN IEC 62311/EN IEC 61000-3-2/EN IEC 61000-3-3
EN 55032/EN 55035/
EN 301 489-1/EN 301 489-3/EN 301 489-17/EN 301 489-52
EN 301 328/EN 301 440/EN 301 511/EN 301 908-1/EN 301 908-2
|
| LCD | ||
| ED-HMI3010-070C | ED-HMI3010-101C | |
| LCD Size |
7.0″ TFT
|
10.1″ TFT
|
| Resolution | 1024 x 600 | 1280×800 |
| Colors | 16.7MB | 16.7MB |
| Active Area |
154.21mm(H) x 85.92mm(V)
|
216.576mm(H) x 135.36mm(V)
|
| Backlight | LED | LED |
| MTBF |
>30000h
|
>30000h |
| Luminance |
400cd/m^2
|
250cd/m^2 |
| Contrast Ratio | 800:1 | 1000:1 |
| Response Time | 30ms | 30ms |
|
Viewing Angle(CR≥10)
|
85°(L)/85°(R)/85°(U)/85°(D) |
80°(L)/80°(R)/80°(U)/80°(D)
|
| Inches |
|
